SeeSnake Mini Pro Inspection Camera with TruSense Technology

Mini Pro

SeeSnake Mini Pro Inspection Camera with TruSense Technology

Mini Pro

The RIDGID® SeeSnake® Mini Pro is our newest TruSense-enabled diagnostic inspection reel. With our smallest and most rugged 25 mm self-leveling camera and mid-flex push cable, the Mini Pro is designed to navigate hard 90° bends and inspect up to 61 m (200'). When used with a TruSense-capable monitor, the Mini Pro’s innovative self-leveling technology produces the most stable in-pipe view, without mechanical rotation. This greatly enhances the longevity and durability of the camera, while lowering the service calls. The TruSense enhanced camera brings valuable in-pipe data to enhance pipe inspections in the field.

Show Less
Read More

Features

  • TruSense Technology - When paired with a TruSense enabled monitor, advanced sensors on the camera head convery valuable information about the in-pipe environment including digital self-leveling, high dynamic range, a TiltSense Inclinometer, and digital pan/zoom.
  • Digital Self-Leveling - Ultra-smooth digital self-leveling keeps image upright with no moving mechanical parts.
  • High Dynamic Range - Offers superior clarity and detail of the in-pipe image displayed on a TruSense enabled monitor.
  • TiltSense™ Inclinometer - Provides the degree of tilt of the camera head while in-pipe and displays it on a TruSense enabled monitor.
  • Digital Pan & Zoom - Adds the ability to focus on a single point of interest.
  • Navigation Flexibility - Equipped with a rugged 25 mm diameter, 0.7 in (18 mm) long camera head and mid-flexibility push cable, this reel is flexible enough to navigate sharp bends while stiff enough to travel long distances in 1 1/2 - 8" (40 - 200 mm) lines.
  • Traceability - A built-in 512Hz FleXmitter® sonde preserves the flexibility to clear tight runs.

Specifications

Camera Diameter 25 mm
Camera Type Digital Self-Leveling
Resolution 640 x 480 pixels
Line Capacity 1 1/2 to 8" (38 mm to 203 mm)
Push Cable Length 200 ft (61 m)
Push Cable Diameter 0.36 in (9.1 mm)
Cable Flexibility Mid Stiff
Push Cable Minimum Bend Radius 3 in (76 mm)
Sonde 512 Hz, FleXmitter®
Weight 26 lb (11.8 kg)
Length 20.4 in (519 mm)
Width 11.3 in (288 mm)
Height 22 in (560 mm)
Drum Diameter 18.2 in (462 mm)

Ordering Information

{{model}}
Catalog Number Model No. Description
76883 Mini Pro  SeeSnake® Mini Pro  Buy Now
  • 67307 - Assy, Interconnect Cable, Overmolded, 3m (10’)
  • 17553 - Spanner Wrench, 25mm
  • 63868 - Various Pipe Guides, 25mm Camera Head
Accessories
{{model}}
Catalog Number Description Weight
lb. kg
17553 Spanner Wrench, 25mm   1/50  0.01  Buy Now
35338 45 mm Pipe Guide, 25 mm Camera, Pkg of 2  Buy Now
46708 85 mm Pipe Guide, 25 mm Camera, Pkg of 2  Buy Now
46713 125 mm Pipe Guide, 25 mm Camera, Pkg of 2  Buy Now
47793 36 mm Pipe Guide, 25 mm Camera, Pkg of 1  Buy Now
63868 Various Pipe Guides, 25mm Camera Head  Buy Now
Replacement Parts
{{model}}
Catalog Number Description Weight
lb. kg
67307 Assy, Interconnect Cable, Overmolded, 3m (10’)  1 1/10  0.50  Buy Now
67327 Kit, 200’ Production Cable & Main Spring – Mini  Buy Now
